Overview

Maximum Power and Versatility

Delivering 1064 nm and 532 nm, with MultiLite Dye Handpieces extending the wavelength capabilities to include 585 nm and 650 nm, RevLite SI provides the versatility you need to target the full color spectrum of tattoo inks. It also allows you to perform non-ablative skin resurfacing, wrinkle reduction, and acne scar reduction, and is proven effective on dermal and epidermal pigmented lesions, including melasma.

RevLiteSI’s advanced technology features include:

  • SmartInfiniteTM (SI) Handpiece
  • MultiLite Dye Handpieces (585 nm and 650 nm)
  • 532Lite Handpiece
  • PhotoAcoustic Technology Pulse (PTP)
  • Precision Beam Technology

Precision That’s Quick and Easy

The Smart Infinite (SI) Handpiece provides continuous 0.1 mm micro-adjustments in spot size, enabling you to easily select the largest spot size with the highest fluence for faster and more efficient treatments. The spot size setting is automatically communicated to the laser control system, making spot size changes quicker and easier than ever.

RevLite SI

More Capabilities

RevLite SI includes MultiLite Dye Handpieces that extend the laser’s wavelength capabilities. The 585 nm (yellow) and 650 nm (red) wavelength handpieces allow for effective full-color tattoo removal.

For precisely treating small pigmented lesions at very low fluences, the 532Lite Handpiece with spot sizes in continual 0.1 mm increments is also part of the RevLite SI system.

Greater Efficacy and Comfort

With proprietary PhotoAcoustic Technology PulseTM (PTP), RevLite SI takes power and short pulse duration one step further. Our exclusive PTP is a unique dispersion of energy that delivers very narrow pulse widths at peak power, for efficient removal of unwanted pigment. Clinical studies indicate that the PTP mode offers greater efficacy and increased patient comfort for skin revitalization.1

1 Yaghmai D, MD, Garden J, MD, Bakus A., PhD, Gold M, MD, Saal B, MD, Goldberg D, MD, Massa M, MD.  Photodamage therapy using an electro-optic Q-Switched Nd:YAG laser. Lasers in Surgery and Medicine. 2010; 42: 699–705.

Specifications

RevLiteSI_579

Before & After




Events & Media

Aesthetic Innovation

September 16-17

Chicago, IL

Join us for a dynamic weekend of education and inspiration from Dr. R. Stephen Mulholland, a pioneer of medical aesthetics,… More

November 10-12

Charlotte, NC

Join us for a dynamic weekend of education and inspiration from Dr. R. Stephen Mulholland, a pioneer of medical aesthetics,… More

See all Aesthetic Innovation Events

On-Demand Webcasts

See all webcasts

News Mentions

Clinical Data

ConBio, a Cynosure Company, is a recognized industry leader whose technology is strongly supported by sophisticated peer-reviewed clinical research.

Peer Reviewed

Tattoo

  1. Gold, M., MD. (2009). Tattoo removal with an electro-optic Q-switched Nd:YAG laser with a unique pulse dispersion. (April 2009). Cosmetic Dermatology, 22 (4).
  2. Karsai, S., MD, Pfirrmann, G., MD, Hammes, S., MD, Raulin, C., MD. (2008). Treatment of resistant tattoos using a new generation Q-switched Nd:YAG laser: Influence of beam profile and spot size on clearance success. Lasers in Surgery and Medicine, 40, 139–145.

Pigmentation | Hori’s Nevus

  1. Hock Leong EE, MBBS, MRCP(UK), Chee Leok Goh, MBBS, FRCP(UK), Khoo, ES-Y. Chan, PhD, Por Ang, MBBS, MRCP(UK). (2006). Treatment of acquired bilateral nevus of ota-like macules (Hori’s Nevus) with combination 532nm Q-switched Nd:YAG laser followed by 1064nm Q-switched Nd:YAG is more effective: Prospective Study. Dermatologic Surgery, 32, 34–40.

Photodamage

  1. Berlin, A., MD, Dudelzak, J., MD, Hussain, M., MD, Phelps, R., MD, Goldberg, D., MD. (2008). Evaluation of clinical, microscopic, and ultrastructural changes after treatment with a novel Q-switched Nd:YAG laser. Journal of Cosmetic and Laser Therapy, 10, 76–79.
  2. Yaghmai, D., MD, Garden, J., MD, Bakus, A., PhD, Gold, M., MD, Saal, B., MD, Goldberg, D., MD, Massa, M., MD. (2010). Photodamage therapy using an electro-optic Q-switched Nd:YAG laser. Lasers in Surgery and Medicine, 42, 699–705.
